Air Tool Flow Control Valve

When utilizing an air tool with an air compressor, determining the right amount of airflow is very important for a safe and efficient result. And this can be achieved through the help of a good Air Tool Flow Control Valve with you. Of course, knowing the flow rate requirements of your air tool application are extremely important when selecting an air pressure flow control valve. In addition, this amazing tool works on effectively reducing the airflow rate in a section of a pneumatic system, resulting in a slower and definite stream. Also, this contributes to the proper regulation of airflow in only one direction. Thus, allowing a free flow of air in the opposite direction.

How Air Tool Flow Control Works?

As flow is directly proportional to speed and that pressure is directly proportional to strength, increasing the flow in an actuator will result in an increase in its speed as well. The same goes for increasing the available pressure. The higher the air pressure, the higher the strength it will produce. Besides, an air flow rate control valve is directly connected to the air tool to control the existing pressure. This causes the air pressure to be expelled from the connection hose at a reduced rate. If you adjust an airflow control valve, you'll notice that it can also manage the existing rate while the speed of the bore can also be controlled. All in all, an airflow control valve's main purpose in different pneumatic applications is to regulate and control the pressure or flow of air coming out from the tools. It offers a wide range of styles, configurations, and port sizes. Aside from that, some airflow control valves can run backward if there is a check valve bypass backward. Also, some of them can regulate airflow while still allowing it to pass through another section, while other types are designed to simply allow the flow to pass, stop, or switch direction. In short, a flow control valve greatly enhances functionality compared to a traditional control valve. So if you're not sure which one to choose for your kind of application, then problems may come your way in the future.

Different Types of Flow Control Valves

As you may know, the different types of airflow control valves come with different purposes. Mostly, it depends on the amount of airflow needed to finish a particular application. It can also best work whether you want to regulate, increase, or decrease the airflow coming out of your tool, carefully choosing the right type of airflow control valve is a must. Take a look at some of the different types and air flow control valve specification you should consider:

Two-Way Directional Control Air Valves

This type of flow control valve passes air in two ports that can either be open or closed. If the air valve ports are closed, then there will be no air that can flow through the valve. On the other hand, if the air valve ports are open, then air can freely move from the first port through the valve in the opposite direction.

Three-Way Directional Control Air Valves

From the name itself, a three-way air control valve has three reliable ports. Each port provides a different purpose. The first port works on connecting the air valve to an actuator or any device. The second port is directly connected to an airflow. And the third port works as an exhaust exit. This type of air valves is frequently connected to actuators in cylinders or used in pairs and connects them to double-acting cylinders.

Four-Way Directional Control Air Valves

Another worth-investing type of air control valve is called a four-way directional control air valve. Just like the first two mentioned above, it has four unique ports where the two of them are directly connected to the actuators, the other one is connected to the airflow, and the last one works as an exhaust pathway.

Spring Offset Air Control Valves

It is used when the direction of the airflow is switched. For instance, if the valve is either closed or open in a two-way directional valve, airflow is either enabled or prevented. But if you want your valve to return to its intended position, you need to release the valve spool through a spring.
